OVERVIEW

Camden CM-2510 Push Plate Switches have 4-1/2″ x 4-1/2″ rectangular faceplates designed for easy installation directly on a double gang electric box. The tubular switches provide virtually silent operation with minimal actuation force.

Compare
Add to wishlist
Categories: ,
Description

ITEM EXTENDED DESCRIPTION:
2Gang Push Plate Key Sw. NO SPST,Wheelchair & ‘Push to Open’

SELECTION CODE:
350

SELECTION CODE DESCRIPTION:
350 ALL ACTIVE SWITCHES

PRODUCT CODE:
VESTIBULE SWITCHES W/ KEYSWITCH

PRODUCT CODE DESCRIPTION:
CM-2020 SERIES

Features:

Heavy Duty Stainless steel construction|ADA compliant|Minimal actuation force|3 year warranty with ‘2 for 1’ replacement

Specifications:

“Std. Finish=US32 / C32D|Temp Range=-40°F to 140°F (-40°C to +60°C)|Dimensions=4-1/2″” x 4-1/2″” x 1-3/16″”
(114mm x 114mm x 30mm)|Push Plate : Contact Type=N/O SPST Momentary|Push Plate : Contact Rating=3 A @ 30 VDC|Key Switch : Contact Type=N/O SPST Maintained|Key Switch : Contact Rating=6 A @ 30 VDC”

Manual

CM_2510_CM_2520_Series-RESOURCE_FILE-manuals-64002_CM_2520_Manual

Reference Guides



CM_2510_CM_2520_Series-RESOURCE_FILE-referenceguides-52806_Push_Plate_Switch_Cross_Reference

Specsheets

CM_2510_CM_2520_Series-RESOURCE_FILE-specsheets-53416_CM_2510_2520_Spec_Sheet_R4
