ITEM EXTENDED DESCRIPTION:
EXIT WATCH Delayed Egress Maglock 1 Door, 15/30 Sec NFPA
SELECTION CODE:
131
SELECTION CODE DESCRIPTION:
131 MAGNETIC LOCKS
PRODUCT CODE:
EXIT WATCH (TM) DELAYED EGRESS MAGLOCKS
PRODUCT CODE DESCRIPTION:
CX-DE 1200 SERIES
Features:
Holding Force up to 1,200 Lbs.|Field Selectable Exit Delay Tme 15 / 30 Seconds|Nuisance Delay Period Either 1, 2 or 3 Seconds|75dB Voice Alerts With LED Segment Bar Displaying Countdown Time & Field Selectable Languages|Automatic / Manual Start-up On Power Restore|Single gang 90db sounder provided for Alarm alerts|Auto Sensing Voltage Power Input 12/24 VDC|Power Polarity Protection|Optional Connection for Auxiliary Lock (Double Leaf Door)|Hall Effect Sensor Monitoring Output|Anti-tamper status|Tailgating Prevention – Door Will Re-lock As Soon As It Closes|Anti-Pass Back / Auto Re-lock:|Optional Features: : Door Position Status|Optional Features: : Bond Status|Optional Features: : Remote Reset and Bypass via Keyswitch
Specifications:
Voltage=12/24 VDC +/- 10% (Auto-Sensing)|Current Draw=600mA / 350mA|DPS Rating=30 VDC, 0.1A (max.)|ATS Rating=30 VAC / 42.4 VDC, 5A (max.)|Lock Status Relay Rating=30 VDC, 2A (max.)|Alarm Output Rating=30 VDC, 2A (max.)|Bond Sensor Rating=CX-DE1200: 30 VDC, 2A (max.)|Holding Force=Up to 1,200 lbs. (544 kg.)|Temperature Range=32°F – 131°F (0°C to 55°C)|Dimensions – Armature Plate=2-5/8″H x 11″W x 1″D (68mm x 280mm x 25mm)|Dimensions – Lock=3″H x 11″W x 3″D (76mm x 280mm x 76mm)
Manual
CX_DE1200_Series-RESOURCE_FILE-manuals-62176_CX_DE1200_Manual_R7
Reference Guides
CX_DE1200_Series-RESOURCE_FILE-referenceguides-61293_CX_DE1200_Product_Comparison_Chart
Specsheets
CX_DE1200_Series-RESOURCE_FILE-specsheets-65399_CX_DE1200_Spec_Sheet_R6
